JuiceBox 500 Portable Power Station 500Wh 800W | Blaupunkt

The Blaupunkt JuiceBox 500 is the perfect companion for outdoor adventures, camping trips, garden parties, or as a reliable emergency backup. With its compact and lightweight design and 500Wh lithium-iron-phosphate battery, it ensures power wherever you go.

portable-power-station-500wh
portable power station 500Wh 3
portable power station 500Wh 2
portable power station 500Wh 4

Description

Type 2 - 16A - 5meter Three Phase EV Charging Cable
Delivering up to 800W output power on 220V through 2 Schuko sockets, the JuiceBox 500 can handle essential electronic appliances.

High-power appliances: approx. 30-45 minutes
Medium-power devices: (e.g. refrigerators, laptops, TVs): 3–8 hours

The clear display shows real-time consumption and remaining runtime. Additionally, multiple USB ports (2×USB 2.0, 1×USB Type-C) charge smartphones and other mobile devices, providing about 25-50 charges for a typical phone. A 12V car socket covers other mobile power needs.









Charging Options

The Blaupunkt JuiceBox 500 offers flexible recharging:

  • Household plug (full charge in less than 1 hour)
  • Car cigarette lighter for charging while driving
  • Solar panels with up to 200W input, making it a sustainable ener5meter Three Phase EV Charging Cablegy solution



Lifespan

Designed for longevity, the JuiceBox 500 endures more than 4000 charging cycles, ensuring years of dependable performance.



Mobile Application

Pair your JuiceBox with the Wonderfree App to control the device remotely. Monitor real-time energy consumption and track internal temperature directly from your smartphone.

Charger Specifications

FeatureValue
Item CodeBPPS500A
SKU100953
Power800W
Battery Capacity500Wh (51.2V)
Battery Cycle LifeLiFePO4 4000+ charge cycles
InverterPure Sine Wave
AC Adapter12V-50V / 11A, Max. 500W
Super Fast ChargeMax. 1200W, 200-240V
AC Charging Timeless than 1.5hours
Solar Panel Connector1* XT60 Port, 12V-50V / 11A, MPPT Max. 500W
Solar Charging Time< 3hours
Car Charging12V/8A, 24V/10A
Pass-through Charging (UPS)Yes
Rated Power800W
UPS Rated Power220-240V / MAX10A
Surge Power3600W 220-240V
Voltage Rated Frequency60Hz/50Hz
Over Load< 1850W Continuously, < 3600W for 1s
Inverter Efficiencyη=92%
Depth of DischargeDOD=90%
EPS Start Time< 10ms
ProtectionShort-circuit, Over-current, Over-voltage, Low-voltage, Over-load, Over-temperature, Over-charge
AC Output4 Schuko * AC 1800W
USB-A, QC3.02 ports * 2 * 18W (5V/3A; 9V/2A; 12V/1.5A)
Type-C11* 20W (5V/3A; 9V/2A; 12V/1.5A)
Type-C21* PD100W (5V3A; 9V3A; 12V3A; 15V3A; 20V5A)
DC55212* 12V/3A socket
Cigarette Lighter Port1* 12V/10A socket
LED Lighting5W LED
Management SystemBMS Management
Charging Temperature0-40 °C / 32-104°F
Discharging Temperature-10-40 °C / -4-104°F
Humidity10%-90%
Cooling Strategy2 Cooling Fans
Shell MaterialABS+PC
Fire RatingV0
DimensionsL346* W228* H251mm
Packing ListBPPS500A*1, AC cable*1, manual *1
WeightN.W.: 12.2kg G.W.: 15.2kg
CertificatesCE (EMC, LVD, RoHS)
Safety DocumentsUN38.3, MSDS
Warranty2 years
